Email when available
El Camino / Small
£2,999 £3,599
Explore more. El Camino is the electric version of our award-winning Camino gravel bike.
At a Glance
- Shimano GRX 1 Groupset 11-speed
- RockShox Rudy suspension fork
- Sonder Alpha EX Wheelset
Progressive geometry
With the same long-distance capabilities as its non-electric counterpart, El Camino doesn't compromise agility, speed or comfort. It's confidence-inspiring over the rough stuff and handles well whether loaded or unloaded.
Born for Britain's B-roads and bridleways, it's ideal for the mixed terrain of multi-day adventures - think the 350km long King Alfred or 230km West Kernow Way.
More miles, more climbs, more fun.
El Camino is to explore more. More miles, more climbs, more fun.
The stand-out feature is its smooth whole-bike riding experience thanks to the latest Kynamic BC250 system. El Camino has a torque sensor in the bottom bracket gauging pedal power and flowing in assistance to match your efforts for a natural ride feel.
Lightweight
Weighing just 3kg more than the non-electric Camino, it's lightweight enough to lift over a locked gate, load on a roof rack, or carry to your hotel room at your chosen overnight stop.
Powerful driving force
El Camino is powerful. Its integrated control panel comes with 3 power settings. Choose your heart rate as you ride: low power for all-day continual assistance, middle power for a sweat-free ride to work, or max power for a 20-mile blast around a local loop.
We balance weight, ride feel and performance with a 250Wh battery housed in the downtube and a 250W rear hub motor to give 45Nm of driving force and a real-life range of up to 70km of assisted riding. Enough for long day rides without significant weight penalty.
The battery complies with all US and EU regulations and does not contain minerals from conflict zones.
A range of over 120km is realistic with the 175Wh range extender that fits to a standard bottle cage mount.
On a mixed terrain ride we've achieved 70km from the built in battery using the lowest power assist setting, based on this, with the addition of the range extender 120km is entirely possible.
Using the higher power settings will drastically affect range, under constant use in the highest power setting we expect to get a range of around 20km, ideal for that quick commute or blast after work.
Various factors can affect range, including temperature, terrain and rider/luggage weight, the figures stated above are guidelines.
Smooth ride feel
El Camino is easy to ride unpowered. Its lightweight and low-drag drive allows you to ride at your road ride speed without assistance. El Camino is designed to invoke a joy-filled ride with power on and off, unlike other e-bikes. UK and EU law states that electric power can only assist up to 15.5mph, so we've obsessed over the details to create a bike that doesn't hold you back on speed.
Destined for adventure
El Camino has ample tyre clearance of up to 50mm and comes with Alpha EX wheelsets. We build the wheels ourselves to our exacting standards, with strong Sapim e-bike rated spokes - 32 hole rear and 28 hole front eyeleted rims. The rear hub drive features a Shimano HG freehub as standard and is compatible with 11-speed cassettes.
El Camino boasts multiple bottle cage and rack mounts for unlimited bikepacking configurations, and internal cable routing completes the signature aesthetic of our Camino family.
**Lead image represents the bike for sale, please see store pics for the actual bike.
Features
Award winning Camino progressive geometry
El Camino shares the same progressive geometry as our award-winning Camino. Long and low; it is agile, quick and comfortable and made with 6061 heat treated aluminium. El Camino is adventure ready with 50mm tyre clearance and internal cable routing, plus multiple bottle cage mounts for unlimited bikepacking options.
![](https://cdn.shopify.com/s/files/1/0253/1626/1993/files/el-camino-detail-1.jpg?v=1708595380")
Hub drive: made for road and gravel
Kynamic BC250 hub drive technology is designed for gravel and road. Reliable and serviceable, it pushes you along without the wear to the chain, derailleurs or cassettes that can be a feature of some mid-drive systems. The low-drag system maintains a comfortable ride with or without assistance.
Kynamic BC250 system
Kynamic is a billion-dollar bike business with warehousing in Europe that can provide spares and replacement parts across Europe within 48 hours should it be necessary. The system is serviceable by Sonder and most, if not all, local bike shops. The 250Wh battery housed in the downtube and a 250W rear hub motor give 45Nm of driving force and a real-life range of up to 70km of assisted riding. Enough for long day rides without significant weight penalty. The battery complies with all US and EU regulations and does not contain minerals from conflict zones. A range of over 120km is realistic with the 175Wh range extender that fits to standard bottle cage mounts.
Top tube integrated control panel
The integrated control panel has a 1.3" OLED display and controls to show current speed, average speed, max speed, ride time, ride distance, odometer. The simple menu lets you change units and view between mph/kmph and shows battery level while on the move.
Alpha EX rear hub drive wheel system
El Camino has ample tyre clearance up to 50mm and comes with Alpha EX wheelsets. We build the wheels ourselves to our exacting standards; with Sapim strong e-bike rated spokes - 32 rear and 28 front on eyeleted rims. The rear hub drive comes with a standard Shimano HG freehub and is compatible with 11-speed cassettes.
Geometry and Sizing
Sizing
Generally we recommend:
X-Small: Riders between 4ft 10in and 5ft 3in (147-160cm)
Small: Riders between 5ft 2in and 5ft 7in (158-173cm)
Medium: Riders between 5ft 6in and 5ft 10in (170-177cm)
Large: Riders between 5ft 9in and 6ft 2in (175-187cm)
X-Large: Riders 6ft 2in and over (187cm +)
You can also take into consideration the standover height to ensure you pick a bike that will be a good fit. If you measure your inside leg and ensure there is a minimum of an inch from the toptube to your crotch this will give you enough seatpost adjustment to find your optimum saddle height.
| Size | X-Small | Small | Medium | Large | X-Large |
|---|---|---|---|---|---|
| Rider height | 4ft 10in - 5ft 3in (147-160cm) | 5ft 2in - 5ft 7in (158-173cm) | 5ft 6in - 5ft 10in (170-177cm) | 5ft 9in - 6ft 2in (175-187cm) | 6ft 2in + (187cm +) |
| ST - Seat tube | 430 | 460 | 490 | 520 | 550 |
| ETT - Estimated top tube | 521.2 | 536.4 | 562.1 | 592.4 | 625.3 |
| HT - Head tube | 130 | 150 | 170 | 190 | 210 |
| HA - Head angle | 69 | 69 | 69 | 69 | 69 |
| AC - Axle to crown | 395 | 395 | 395 | 395 | 395 |
| SA - Seat angle | 74.5 | 74.5 | 74 | 74 | 73 |
| CS - Chainstay | 440 | 440 | 440 | 440 | 440 |
| BB - BB drop | 73 | 73 | 73 | 73 | 73 |
| FO - Fork offset | |||||
| WB - Wheelbase | 1033.7 | 1056.7 | 1078.8 | 1111 | 1138.2 |
| SO - Stand over | 765.9 | 773.9 | 812.4 | 834.7 | |
| RE - Reach | 370 | 380 | 395 | 420 | 440 |
| SK - Stack | 545.2 | 563.9 | 582.6 | 601.2 | 616.9 |
Frame Spec
Lightweight, durable and strong titanium frame.
| Weight: S: 1.92 kg; M: 2.0 kg; L: 2.05 kg; XL: 2.16 kg (Plus fork: 0.5kg) |
| Aeronautical grade titanium |
| One piece carbon monocoque fork (Cage mounts on carbon fork designed for 2kg maximum load) |
| Seatpost diameter: 31.6mm |
| Seat tube OD: 34.9mm |
| Headset: IS42/28.6 | IS52/40 |
| Disc brake only |
| Mud guard and pannier rack mounts |
| 700 x 50mm or 650b x 2.2” tyre clearance. |
| 12mm bolt through axles at both ends. |
| Hub spacing: 100x12mm front, 142x12mm rear |
